24000 BTU Air Conditioner - 2 Ton Solar AC Unit

REF-SAC-24

Powerful cooling powered directly by the sun.
The Refria 24000 BTU air conditioner (2 ton) is a heavy-duty solar AC unit designed for large commercial spaces, open offices, and bus stations. This 24000btu unit requires no batteries or inverters, automatically balancing 5 x 550W solar panels and grid AC power to cut your daytime electricity bills by up to 97%.

Key Highlights:
Capacity: 24000 BTU / 7000W (Perfect for 35-50㎡)
Solar Setup: Requires 5 × 550W solar panels
Efficiency: SEER 35 (Solar Mode) / SEER 23 (Grid Mode)
Working Temp: -10°C to +52°C (T3 Environment)

Quantity:

Contact Now

Heavy-duty solar AC unit system with up to 97% daytime electricity savings

ETL

CE

ISO

IEC

SASO

SEER 35

Max Efficiency

5 × 550W

Solar Panels Required

35-50 ㎡

Recommended Area

Why Choose This 24000 BTU Air Conditioner?

The 24000 BTU (7000W) model is a heavy-duty solar AC unit, equivalent to a standard 2 ton air conditioner. It is designed for large commercial spaces, open-plan offices, and public transport hubs. Featuring Direct Solar Drive technology, it runs directly off your solar panels during the day without batteries or inverters. It automatically balances solar and grid power, ensuring powerful, uninterrupted cooling while drastically reducing your daytime energy costs.

How the 2 Ton Solar AC Unit Works

Solar Panels

5 x 550W

➔

DC Breaker

Protection

➔

AC/DC Outdoor Unit

Auto-Balance

Grid Power (AC) Backup

24000 BTU Technical Specifications

Model	GL-ADC24GW-XA-R32
Power Supply Source	220-240V 50Hz/60Hz
Cooling Capacity	7000 W / 24000 BTU (2 Ton)
Heating Capacity	7200 W
Rated Power Consumption (Cooling)	2100 W
DC Input Range	DC 90-380V (MAX 20A)
Indoor Noise Level	48 dB(A)
Outdoor Noise Level	56 dB(A)
Refrigerant	R32 / 1260g
Recommended Solar Panels	5 × 550W

Ideal Applications for 24000 BTU

Large Commercial Spaces

Perfect for 35-50㎡ spaces like supermarkets and restaurants. This 2 ton air conditioner handles heavy cooling loads efficiently during peak business hours.

Open Offices & Halls

Provides powerful, distributed cooling for large open-plan offices, conference halls, and co-working spaces, drastically cutting daytime AC costs.

Bus Stations & Public Hubs

Highly reliable and sustainable cooling for public transport waiting areas, bus stations, and large infrastructure hubs.

Estimated Economic Benefits

By using this 24000 BTU solar AC unit, you can drastically reduce your daytime electricity bills. Here is a typical case study based on 180 operating days per year:

Metric	Data
Annual Electricity Saving	1238 kWh
Payback Time (USA Example)	23 Months (At $1.20/kWh)
Payback Time (Germany Example)	10 Months (At €2.87/kWh)

* Data is for reference only. Actual savings depend on local electricity rates, sunshine hours, and usage habits.

Frequently Asked Questions

Q: Does this 2 ton air conditioner work at night?

A: Yes. The hybrid system automatically switches to AC grid power when there is no sunlight, ensuring uninterrupted cooling.

Q: Do I need a battery for this solar AC unit?

A: No battery is required. The unit uses a direct DC drive. However, you can add a battery backup system if you want completely off-grid night operation.

Q: How many solar panels do I need for this 24000 BTU unit?

A: We recommend connecting 5 standard 550W solar panels to achieve optimal performance.
